This solution is used at:
Pitz Alpine Glacier Trail
Tirol, Austria
The Pitz Alpine Glacier Trail 2021 was timed by Timit using the Passive System. The ~1.000 participants could decide between distances of up to 105 km. Such an event is the perfect terrain for the Track Box Passive. The density at the split points is low, volunteers can easily carry the boxes to the timing location and set them up. The boxes are controlled remotely with RACE RESULT 12 software and send their timing data live. At major timing points (start, finish) with a higher density of runners, the combination of Decoder and Ground Antenna is ideal. For the whole event, a total of 7 Decoders and 7 passive Track Boxes were used. The timing could be managed by only one person!
RACE RESULT makes trail running timing easy, even in the most remote locations. With our Track Box Passive, there’s no need for buslky setups. Just place the lightweight boxes along the course and get live race times straight to your software.
Hands-free, reliable, and built for the toughest trails. Trusted by world-class organizers worldwide, and scalable for events of any size.
Super-easy setup
No more need to carry bulky timing systems to remote locations. Track Boxes are 1.7 kg light and run on internal battery.
Live data transmission
Via 4G network, you instantly receive live data from remote locations. This also helps race marshals to keep track of all participants.
Hands-free
No manual scanning of transponders required. Once setup, the TrackBox automatically detects all transponders passing by.
If the start and finish are in the same place, you only need a single timing system with Ubidium and ground antenna. Set the system up at the finish line, connect it to a laptopand you're ready to start providing real-time results.
The Track Box Passive is set up at the checkpoints. Runners are detected across trails up to four meters wide, provided the density of runners is not too high. The timing data is sent live to the timing software (your laptop needs an internet connection for this). The Track Box can be operated with RACE RESULT SIM cards, these offer above-average reception on any available mobile network.
If the start and finish are at different places, you can use the gun time (every participant has the same start time), install another timing system at the start or you may even have time to move your system from start to finish.
In RACE RESULT 12, our timing software, use the "Standard Event" template. This provides a perfect starting point and may already bring all you need.
Ubidium
The cutting-edge timing system designed for superior performance and versatility. Boasts exceptional weatherproofing, lightweight design, and up to 32 hours battery life. Data is transmitted in real-time through multiple options, including SIM, Ethernet, POE, or USB-C connections.
Ubidium Foldable Ground Antenna
Delivers unprecedented flexibility and the highest detection rates. Each element contains a specially developed RACE RESULT UHF reader. The mat connects directly to Ubidium. It can be adjusted in length as desired, up to 23 meters per system (30 segments).
Track Box Passive (Optional)
UHF transponder timing with only one small device. Eeasy to carry, super fast in setup and managed remotely. With UHF reader, GPS and battery integrated, it is the ideal device for split points, remote timing locations and advanced race visualization. Internal battery for 10-18 hours. Can also be powered by solar panel or external sources.
Bib with Transponder
UHF transponders specially developed for sports timekeeping. Praised by customers worldwide for highest detection rates. The accuracy is 0.2 s. Transponders are available on roll or ready-attached to a customized, personallized Tyvek bib.
RACE RESULT 12 Software
The complete software for timing and managing of any kind of sports event. The intuitive user interface allows you to setup events without complicated formulas or calculations. Featuring registration, event timing, scoring, live results and various output options in one browser-based solution.
Talk to our Experts
Our team has supported events of all sizes across the globe — and we're here to help you too. Get expert advice on the ideal timing setup for your race.
| rent | buy | ||
| Ubidium Bundle 4.6 m Ubidium + 4.6 m Ground Antenna |
n.a. | 4,990 EUR | per system |
| RACE RESULT System 5000s, 4.8m Decoder + 4.8m Ground Antenna |
320 EUR | n.a. | per system |
| Bib A5 with Transponder (single) | 1.18 EUR - 1.40 EUR | per race number | |
| RACE RESULT Track Box Passive Set | 320 EUR | 2,890 EUR | per case with 2 boxes |
| Safety Pins to attach the transponder |
7.41 EUR | per 1000 units | |
| Software RACE RESULT 12 including online registration |
0.09 EUR - 0.32 EUR | per participant |
|
| Optionally: payment processing for online registration |
1%-5% plus transaction fee
depending on the payment method |
||
| All prices plus VAT / tax if applicable | |||
Download
Everything you need to know about the timing solution at a glance:
